EVOCA EVO

Pellet stoves

EVOCA EVO

pellet stove, forced convection, 3 fans, ducted

Round shape and sophisticated design, Evoca can be easily adapted to both classic and modern style interiors. The sides, the top and the plinth are covered in majolica. The sides are engraved with an elegant oval motif. The splaying emphasizes the silk-screened glass and the broad vision of the fire. Evoca has a steel structure and majolica coating, and it is available in three colours: glossy white, cream, glossy bordeaux.

Technological evolution (EVO)

Customization and adaptability to any type of environment

Possibility for the user to adjust the pellet combustion calibration

Predisposition for the combustion air channeling

Silence and maximum comfort

Minimal and easy maintenance: the cleaning of the stove is quick and easy

Reduction of consumption of pellets for greater savings

Reduction of polluting emissions

Maximum adaptability to every type of pellet, to the flue and to the different types of installation for an effective and controlled combustion

Infallibility and ignition speed

Possibility to manage two independent ducts using external probes or thermostats

Maximum performance: double efficient heat exchange, one for heating the ambient air and one for the channeling air

NX EVO2

structure body and cladding: L 59 x P 55,5 x H 111 cm

European reference standard for pellet stoves European Directive for biomass domestic appliances: stoves, fireplaces and kitchens (Regulations UE 2015/1185) European standards conformity mark
Find reseller Request information

Available versions

glossy white

glossy white

cream

cream

glossy bordeaux

glossy bordeaux

Technical data

  classe-AA
  NX10 EVO2
global thermal output 10,2 kW
nominal thermal output 3,5 - 9,0 kW
power rendered to the ducting 2,5 + 2,5 (55%) kW
CO emission at 13% oxygen 0,0090 %
efficiency 88,5 %
fuel consumption 0,8 - 2,1 kg/h
smokes mass flow 3,3 -6,8 g/s
smokes temperature 86 - 171 °C
flue draught pressure 6 Pa
fuel capacity 17 Kg
autonomy 21 - 8 h
fuel exite pipe Ø 80 mm
combustion air intake Ø 60 mm
net weight 78 kg
weight with packaging 89 kg
NX EVO2

Features

pellet stove, forced convection, 3 fans, ducted
