claddings for fireplaces

FRAME

marble frame

The large external frame, in brushed Vicenza stone, plays with concave geometries, which enhance the interior passepartout in absolute black granite, flamed and brushed, and the broad vision of fire. Frame adapts easily to both classic and modern interiors.

LIGHT 06 is the wood-burning fireplace characterised by its rectangular shape with a horizontal development “extralarge”. The door is entirely made of ceramic glass with an up-and-down mechanism and a flap opening for cleaning. Combustion chamber lined with CMtech®, a refractory made with significant thicknesses; in the upper part the Catalyst-Flame Breaker is made of CMtech®2, a ceramic refractory. The fireplace can be completed with two optional hot air distribution kits in both natural and ventilated versions.

LIGHT 06

FRAME
European Directive for biomass domestic appliances: stoves, fireplaces and kitchens (Regulations UE 2015/1185) European standards conformity mark European reference standard for pellet stoves
Find reseller Request information

Available versions

FRAME 01 wood burning <br> with LIGHT 01

FRAME 01 wood burning
with LIGHT 01

FRAME 02 wood burning <br> with LIGHT 02

FRAME 02 wood burning
with LIGHT 02

FRAME 06 wood burning <br> with LIGHT 06

FRAME 06 wood burning
with LIGHT 06

Technical data

  classe-AA classe-AA
  LIGHT 06 21N LIGHT 06 22V
   natural convection  ventilated
Quality class (DM 186 - 7/11/2017) 4-stelle 4-stelle
Global thermal output 20,5 21,7 kW
Nominal thermal output 17,0 18,5 kW
CO emission at 13% of oxygen 0,0999 0,0940 %
Efficiency (η) 83 85 %
Primary Particulate (PP) (at 13% oxygen) 20 19 mg/Nm3
COT (at 13% oxygen) 20 21 mg/Nm3
Fuel consumption 4,6 4,8 kg/h
Smokes mass flow 14,0 19,0 g/s
Smokes temperature 225 162 °C
Flue draught pressure 12 12 Pa
Fuel exite pipe Ø 250 Ø 250 mm
Internal flue section Ø 25 / 25x25 Ø 25 / 25x25 cm
Minimum flue height 5 5 m
Air inlet ducts 2 x Ø 15 2 x Ø 15 cm
Heatable surface with certified power 195 212 *mq
Net weight - Weight with packaging 289 - 316 306 - 335 kg

Features

marble frame
