claddings for fireplaces

FRAME

marble frame

The large external frame, in brushed Vicenza stone, plays with concave geometries, which enhance the interior passepartout in absolute black granite, flamed and brushed, and the broad vision of fire. Frame adapts easily to both classic and modern interiors.

The LIGHT 01 one-piece wood-burning fireplace with an all-ceramic glass door, which can be opened with ups and downs for easy cleaning. The combustion chamber is lined with CMtech®, a light-colored refractory material made with significant thicknesses. In the upper part the Catalyst-Flamebreaker is made of CMtech®2 ceramic refractory. The fireplace can be integrated with two optional kits for air ducting and distribution. The first kit keeps the fireplace natural convection, while the second converts it to ventilated and forced air.

LIGHT 01

FRAME
European Directive for biomass domestic appliances: stoves, fireplaces and kitchens (Regulations UE 2015/1185) European standards conformity mark European reference standard for pellet stoves
Find reseller Request information

Available versions

FRAME 01 wood burning <br> with LIGHT 01

FRAME 01 wood burning
with LIGHT 01

FRAME 02 wood burning <br> with LIGHT 02

FRAME 02 wood burning
with LIGHT 02

FRAME 06 wood burning <br> with LIGHT 06

FRAME 06 wood burning
with LIGHT 06

Technical data

  classe-AA
  LIGHT 01
  natural convection
Quality class (DM 186 - 7/11/2017) 4-stelle
Global thermal output 13,9 kW
Nominal thermal output 12,0 kW
CO emission at 13% of oxygen 0,065 %
Efficiency (η) 86 %
Primary Particulate (PP) (at 13% oxygen) 19 mg/Nm3
COT (at 13% oxygen) 39 mg/Nm3
Fuel consumption 3,10 kg/h
Smokes mass flow 8,1 g/s
Smokes temperature 256 °C
Flue draught pressure 12 Pa
Fuel exite pipe Ø 180 mm
Internal chimney section Ø 18 / 18x18 cm
Minimum flue height 4 m
Heatable surface with certified power 138 *mq
Net weight - Weight with packaging 191 - 206 kg

Features

marble frame
