COMPACT 80V
COMPACT 80V

Wood inserts

COMPACT 80V

Ventilated and ducted hot air wood insert with reversible door made entirely of ceramic glass

Wood-burning insert with ventilated and channeled hot air with reversible door entirely in ceramic glass. Compact is available in 80 cm size. Thanks to its simple lines, it easily adapts to any type of environment. The beauty of simplicity: combustion chamber complete with catalyst-flame arrester lined with CMtech 2, ceramic refractory, with cast iron fire bed. Wide view of the fire.
Available with black painted steel frame.

COMPACT 80V

COMPACT 80V

COMPACT 80V + MINIMAL 80V

European Directive for biomass domestic appliances: stoves, fireplaces and kitchens (Regulations UE 2015/1185) European standards conformity mark European reference standard for pellet stoves
Find reseller Request information

Technical data

  classe-AA
  COMPACT 80V
Quality class (DM 186 - 7/11/2017)
Global thermal output 11,1 kW
Nominal thermal output 9,5 kW
CO emission at 13% of oxygen 0,0901 %
Efficiency (η) 85 %
Primary Particulate (PP) (at 13% oxygen) 20 mg/Nm3
COT (at 13% of oxygen) 43 mg/Nm3
Fuel consumption 2,68 kg/h
Smokes mass flow 8,0 g/s
Smokes temperature 205 °C
Flue draught pressure 12 Pa
Smokes exite pipe Ø 200 mm
Internal flue section Ø 20 cm
Minimum flue height 3 m
Heatable surface with certified power 109 *mq
Net weight - Weight with packaging 120 - 130 kg
* with the conditions reported in the General Catalogue

Features

Ventilated and ducted hot air wood insert with reversible door made entirely of ceramic glass
