Wood fireplaces

TK 03F

wood-burning fireplace

TK 03F

European reference standard for inserts and fireplaces European Directive for biomass domestic appliances: stoves, fireplaces and kitchens (Regulations UE 2015/1185) European standards conformity mark

Technical data

  classe-AA
  TK 03F
  natural convection
output 8,8 kW
nominal thermal output 7,5 kW
CO emission at 13% oxygen 0,09 %
efficiency 85,2 %
average fuel consumption 2,4 kg/h
flue gas mass flow 8 g/s
flue gas temperature 220 °C
flue draught pressure 11 Pa
flue exite pipe Ø 180 mm
internal section of chimney flue Ø 18 cm
min. height of chimney flue 4 m
air inlet ducts Ø 15 cm
net weight 215 kg
weight with packaging 230 kg
TK 03F
