CM P05 EP

Wood fireplaces

CM P05 EP

wood-burning fireplace

The CMP05 EPwood-burning fireplace offers a seamless view of the fire on two sides, thanks to ceramic glass made from a single shaped plate. It is distinguished by the corner door with painted steel edge, which opens up and down with stainless steel handle. The door opening makes cleaning easier.

CM P05 EP

CM P05 EP
European Directive for biomass domestic appliances: stoves, fireplaces and kitchens (Regulations UE 2015/1185) European standards conformity mark European reference standard for pellet stoves
Find reseller Request information

Technical data

  classe-AA
  CM P05 EP
   natural convection
Quality class (DM 186 - 7/11/2017) 5-stelle
Global thermal output 16,7 kW
Nominal thermal output 14,4 kW
CO emission at 13% of oxygen 0,0496 %
Efficiency (η) 86 %
Primary Particulate (PP) (at 13% oxygen) 9 mg/Nm3
COT (at 13% oxygen) 12 mg/Nm3
Fuel consumption 3,6 kg/h
Smokes mass flow 12,4 g/s
Smokes temperature 195 °C
Flue draught pressure 22 Pa
Fuel exite pipe Ø 150 mm
Internal flue section Ø 18 / 18x18 cm
Minimum flue height 4,5 m
Air inlet ducts 2 x Ø 12 cm
Heatable surface with certified power 165 *mq
Net weight - Weight with packaging 236 - 259 kg
CM P05 EP

Features

wood-burning fireplace
