Wood fireplaces

BK 02F

wood-burning fireplace

BK 02F

European reference standard for inserts and fireplaces European Directive for biomass domestic appliances: stoves, fireplaces and kitchens (Regulations UE 2015/1185) European standards conformity mark

Technical data

  classe-AA
  LIGHT 02N
  natural convection
output 13,0 kW
nominal thermal output 11,0 kW
CO emission at 13% oxygen 0,08 %
efficiency 84,4 %
average fuel consumption 5,5 kg/h
flue gas mass flow 8 g/s
flue gas temperature 260 °C
flue draught pressure 11 Pa
flue exite pipe Ø 200 mm
internal section of chimney flue Ø 20 cm
min. height of chimney flue 4 m
air inlet ducts Ø 15 cm
net weight 275 kg
weight with packaging 290 kg
