ASTA
ASTA
ASTA

Pellet stoves

ASTA

with SPS10 stove body, slim, hermetic with ventilated hot air and ductable with smart SMART ventilation that makes the stove extremely quiet.

The pellet stove ASTA is hermetic with hot ventilated and ductable with intelligent SMART air ventilation which makes it extremely silent.
Available in white with majolica cladding.

• 5 stars

• Reduced depth to limit space clutter

• Control panel featuring a backlit graphic display with digital icons TOUCH SCREEN

• Cylindrical cast iron burner equipped with flame arrester deflector

• Double side heat exchanger

• Chronothermostat with adjustable temperature and power

• Efficient combustion control system TUTOR

• Tangential ambient air fan

• Channelable centrifugal air fan

• Rear or upper fume exhaust to reduce bulk spaces

• Wi-Fi module (optional)

SPS

ASTA

dimension: W 86 x D 33 x H 111 cm

European Directive for biomass domestic appliances: stoves, fireplaces and kitchens (Regulations UE 2015/1185) European standards conformity mark European reference standard for pellet stoves
Find reseller Request information

Available versions

white

white

Technical data

  classe-AA
  SPS10
Quality class (DM 186 - 7/11/2017) 5-stelle
Global thermal output 10,0 kW
Nominal thermal output 3,2 - 9,1 kW
Power rendered to channeling* 4,0 kW
CO emission at 13% of oxygen 0,0031 %
Efficiency (η) 91 %
Primary Particulate (PP) (at 13% oxygen) 15 mg/Nm³
COT (at 13% oxygen) 2 mg/Nm³
Fuel consumption 0,69 - 2,06 kg/h
Smokes mass flow 3,0 - 6,5 g/s
Smokes temperature 71 - 151 °C
Flue draught pressure 12 Pa
Fuel capacity 21,0 Kg
Autonomy 30,0 - 10,0 h
Fuel exite pipe Ø 80 mm
Combustion air intake Ø 50 mm
Heatable surface with certified power 104 *mq
Net weight - Weight with packaging 92 - 105 kg
