VENGHÈ
VENGHÈ
VENGHÈ

claddings for fireplaces

VENGHÈ

marble frame

The large frame in precious Pietra Venghè, with 45 ° angular cuts, easily adapts to environments furnished in both classic and modern style, thanks to the warm tones and minimal design.

The LIGHT 02 wood-burning fireplace is characterised by the width of the door made entirely of ceramic glass with a drop-down and drop-down opening for cleaning. Combustion chamber lined with CMtech®, a refractory made with significant thicknesses; in the upper part the Catalyst-Flame Breaker is made of CMtech®2, a ceramic refractory.

LIGHT 02

VENGHÈ
European Directive for biomass domestic appliances: stoves, fireplaces and kitchens (Regulations UE 2015/1185) European standards conformity mark European reference standard for pellet stoves
Find reseller Request information

Available versions

VENGHÈ 02 <br> with LIGHT 02

VENGHÈ 02
with LIGHT 02

VENGHÈ 80L <br> with LIGHT 80 S

VENGHÈ 80L
with LIGHT 80 S

VENGHÈ/M <br> wih MB MEGAFIRE <br> VENGHÈ/M <br> with MB MEGAIDRO W

VENGHÈ/M
wih MB MEGAFIRE
VENGHÈ/M
with MB MEGAIDRO W

Technical data

  classe-AA classe-AA
  LIGHT 02N S LIGHT 02V E
  natural convection ventilated
Quality class (DM 186 - 7/11/2017) 4-stelle 5-stelle
Global thermal output 15,6 19,6 kW
Nominal thermal output 13,0 16,7 kW
CO emission at 13% of oxygen 0,086 0,0418 %
Efficiency (η) 83 85 %
Primary Particulate (PP) (at 13% oxygen) 24 14 mg/Nm3
COT (at 13% oxygen) 56 29 mg/Nm3
Fuel consumption 3,5 4,61 kg/h
Smokes mass flow 11,5 15,2 g/s
Smokes temperature 214 192 °C
Flue draught pressure 12 11 Pa
Fuel exite pipe Ø 200 Ø 200 mm
Internal flue section Ø 20 / 20x20 Ø 20 / 20x20 cm
Minimum flue height 4 4 m
Air inlet ducts 2 x Ø 15 2 x Ø 15 cm
Heatable surface with certified power 149 192 *mq
Net weight - Weight with packaging 235 - 258 255 - 278 kg
LIGHT 02

Features

marble frame
