claddings for fireplaces
marble cladding
The Bianco Panna marble of the top and the reversible bench and the large base in Pietra Venghè create refined chromatic effects, emphasized by the light from the lighted flame. Design is an intriguing play of lines and volumes. Moreover, Slide is equipped with a blade under the hood in black painted steel.
CMP 05N | CMP 05V | |||
natural convection | forced convection | |||
output | 14,3 | 12,9 | kW | |
nominal thermal output | 11,0 | 11,0 | kW | |
CO emission at 13% oxygen | 0,052 | 0,052 | % | |
efficiency | 77,0 | 85,4 | % | |
average fuel consumption | 2,51 | 2,28 | kg/h | |
flue gas mass flow | 12,7 | 10,1 | g/s | |
flue gas temperature | 256 | 188 | °C | |
flue draught pressure | 12 | 12 | Pa | |
flue exite pipe | Ø 180 | Ø 180 | mm | |
internal section of chimney flue | Ø 18 / 18x18 | Ø 18 / 18x18 | cm | |
min. height of chimney flue | 4 | 4 | m | |
air inlet ducts | 2 x Ø 12 | 2 x Ø 12 | cm | |
net weight | 234 | 237 | kg | |
weight with packaging | 257 | 260 | kg |
caminetto a legna con visione del fuoco su due lati senza interruzioni, grazie al vetro ceramico in un’unica lastra sagomata. Si distingue per la porta ad angolo con bordo in acciaio verniciato, apribile a saliscendi con maniglia in acciaio inox; apertura ad anta per la pulizia. Camera di combustione completa di Catalizzatore-Frangifiamma rivestita in CMtech®2, refrattario ceramico, con piano fuoco in ghisa. Sono disponibili versioni ad aria calda ventilata o a convezione naturale.
